HT-8822 F-N HT-8822 Dual Function Coating Thickness Gauge

1 Piece
MOQ
HT-8822 F-N HT-8822 Dual Function Coating Thickness Gauge
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Years
Model Number: HT-8822
Product Name: Coating Thickness Gauge
Principle: F Magnetic Induction & NF Type Eddy Current
Range: 0~1000um/0~40mil
Resolution: 0.1um/1um
Accuracy: ±1~3%n Or ±2.5um
Min.Radius Workpiece: F Type:convex 1.5mm/concave 25mm NF Type:convex 3mm/concave 50mm
Min.Measuring Area: 6mm
Metric/Imperial: Convertible
Power Supply: 4x1.5V AA (UM-3)Battery
Dimensions: 161x69x32mm
Basic Infomation
Model Number: HT-8822
Payment & Shipping Terms
Packaging Details: carton
Product Description

Applications:

Coating thickness gauge is a kind of portable measuring instrument, can take fast, intact, precise measurement of coating thickness. It can not only be used in engine-ering field, laboratories, but also meet the demand of multiple measuring by using different probes. It is used widely in manufacturing, metal processing industry,chemical industry, commodity inspection field, etc. As an essential instrument in material protection industry.

Features:

1.Two principles: Magnetic Induction and Eddy Current.
2.Two measurement mode: Single and Continuous.
3.Metric/imperial system selectable.
4.Manual or automatic power off.
5.Automatic memory of calibration value,and automatic recognize the substrate.
6.Operation process have buzzing reminder.
7.Integral Type have better stability and repeatability.
8.Separate Type can provide several types of probes,measure can be more flexibility.

Beijing Hantai Technology Development Co., Ltd. is a high-tech enterprise with import and export rights. The company mainly specializes in industrial ultrasonic flow meters, Leeb hardness testers, digital ultrasonic thickness gauges, coating thickness gauges, digital ultrasonic flaw detectors, etc. Sales and after-sales service of a number of non-destructive testing products, gas testing equipment and safety protection, environmental protection equipment, construction testing equipment, steel structure and other equipment. The company is headquartered in Beijing and has offices in Hangzhou.

We will, as always, adjust our work direction according to market changes and user needs, and always adhere to work with manufacturers to provide users with professional pre-sales technical support and timely and accurate after-sales technical services, adhere to the principle of customer first, and implement " Seamless service".

Based on the business philosophy of "Wisdom, Integrity, Professionalism, Innovation", the company warmly welcomes new and old customers and people of insight at home and abroad to sincerely cooperate and create a brilliant future!
