EC-420 1500um handheld coating thickness gauge
This coating thickness gauge has a built-in magnetic induction and eddy current integrated probe, supporting 0~1500μm measurement range,±(3%+1μm) accuracy and 0.1μm resolution.
| Model | EC-420 | |
| Probe | Probe F | Probe N |
| Measuring principle | Magnetic Induction | Eddy currents |
| Measuring range | 0~1500μm | |
| Accuracy | ±(3%+1μm) | |
| Resolution | 0.1μm(0~100μm);1μm(>100μm) | |
| Calibration mode | Zero calibration | |
| Statistics | No. of readings, mean, minimum, maximum | |
| Units | μm, mm, mils | |
| Minimum radius of curvature of substrate | Convex 5 mm; Concave 25 mm | |
| Minimum measured area | Diameter 20mm | |
| Minimum thickness of substrate | 0.30mm | 0.05mm |
| Maximum measuring speed | 2 times / second | |
| Display | Segment code LCD screen with backlight | |
| Operation buttons | Power (Backlight), unit switching and clearing data (Left), statistics and zero calibration (Right) | |
| Operation temperature | Temperature:-10℃~50℃;Humidity:20%RH~90%RH(Non-condensation) | |
| Storage temperature | Temperature:-10℃~60℃;Humidity:20%RH~90%RH(Non-condensation) | |
| Power supply | 9V square battery | |
| Protection class | IP40 | |
| Size | 143mmX85mmX39mm | |
| Material | ABS | |
| Weight | About 100g(No battery) | |
| Warranty | 12 months | |
